Pulse Subtab - Terumo Advanced Perfusion System 1 Operator's Manual

Central Control Monitor

Pulse Subtab

The Pulse subtab can be used to adjust pulse parameters and initiate Pulse mode for
a roller pump or centrifugal pump designated as the primary pump.
Roller Pump Pulse Parameters
The Rate, Width, and Base are set up using the Pulse subtab.
Arterial
Summary
100%
Servo
50%
Pulse
To Set the Rate:
1. Touch the Rate button.
2. Use the large arrows to change the Rate in increments of 10 beats per minute.
3. Use the small arrows to change the Rate in increments of 1 beat per minute.
4. Touch the Rate button again to store the new value.
To Set the Base:
1. Touch the Base button.
2. Use the large arrows to change the Base in increments of 10%.
3. Use the small arrows to change the Base in increments of 5%.
4. Touch the Base button again to store the new value. The recommended
minimum Base is 30%.
To Set the Width:
1. Touch the Width button.
2. Use the large arrows to change the Width in increments of 10%.
3. Use the small arrows to change the Width in increments of 5%.
4. Touch the Width button again to store the new value. The recommended
minimum Width is 30%.
See the Roller Pumps chapter for details of Pulse mode operation.
1
The use of the term "Pulse mode" refers to the variable pressure and flow
waveforms that result from the cyclic operation of the primary pump. Replication
of a physiologic pulse from a natural heart is not obtained with a pump speed
controller. No claim of clinical benefit from the use of the Pulse mode has been
reviewed by global Regulatory Agencies.
Pulse Control:
60 BPM
Rate:
85%
Base:
Auto Auto
Manual
Width: 50%
4-36
