Terumo Advanced Perfusion System 1 Operator's Manual page 261

Modules
Interface Module RS-232
Connect Data Transfer Module
1. Attach the serial cable to the appropriate data transfer module.
2. Insert module into base receptacle as close as possible to the location where the
data collection system will be used.
3. Connect the serial cable to the data collection system.
4. Route the cable to minimize exposure to spills.
C D
I 5
0 0
Refer to the TLink™ Data Management System manual for instructions for using the
software.
Data Transfer
Data transfer takes place after a Perfusion Screen is opened on the CCM. Only
devices and/or modules that are online will transmit data.
Perfusion data is exported from the module at least every 30 seconds. In addition,
events are also exported when they occur. The data includes a System 1 time stamp
and is identified by its system assigned label.
7-38
