Central Control Monitor
Add a Device
To add a device to the graphic display, touch the Add button.
To Add Device:
Select Device Type:
Air Detector
Level Detector
Occluder
Pressure Sensor
Flow Sensor
Temperature Sensor
CDI 100
CDI 500
Current defined:
Maximum allowed
Select Device Type
Choose Device Type by touching the type name. Use the arrows to scroll through the
list of device types.
The number of currently defined devices of that type and the maximum number of
devices of that type are displayed in the box below the list.
Touch Cancel to cancel the addition of a device.

Add Air Detectors

Up to 4 Air Detectors can appear on a Perfusion Screen.
It is highly recommended that an Air Bubble Detection system is used on the arterial
line for every case.
To add an Air Detector:
1. Choose Add.
2. Choose Air Detector as device type.
3. Name the air detector.
4. Touch the Next button.
To Add Device:
Select Device Type:
Air Detector
Level Detector
Occluder
Pressure Sensor
Flow Sensor
Temperature Sensor
CDI 100
CDI 500
Current defined:
Maximum allowed
Select Device Name: Select Device Name:
Select From List:
Or Enter New Name:
Or Enter New Name:
0
Enter New Name > Enter New Name >
0
Select Device Name:
Select From List:
ART Air
VEN Air
CPG Air
CPG1 Air
CPG2 Air
Or Enter New Name:
0
4 Enter New Name >
4-66
Next >
Next > Cancel
Next > Cancel
