Terumo Advanced Perfusion System 1 Operator's Manual page 161

Central Control Monitor
The device name moves from the Assigned list to the Unassigned list and
disappear from the Assigned box in the top of the screen. In order to assign a
device that has been previously assigned to a different module, it must first be
unassigned, and then reassigned.
Assign Configuration Device to Physical Module: Pressure Sensors
1. On the base, locate the module with the green flashing light.
Select 'Channel 1' or 'Channel 2'.
Channel 1
Channel 2
2. To assign a configuration device to the selected channel:
Touch the device in the unassigned list, then touch the 'Assign' button.
Repeat the process for the other channel.
Unassigned:
3. To assign another Pressure Sensor device:
Touch the 'Go to Next Module' button and repeat from step 1.
3. To assign another device of the same type, touch the 'Go to Next Module'
button and repeat from step 1.
Continue until all devices of the same type on the graphic display have been
assigned to physical modules on the system base. Once the assignments are
complete, touch the OK button.
Assigned: ART Pres
Assigned: ART Pres
Assigned: CPG Pres
Assigned:
ART Pres
Assign > Assign >
CPG Pres
< Unassign
OK
4-95
Go to Next Module
Cancel
