System Components - Terumo Advanced Perfusion System 1 Operator's Manual

Additional Information

System Components

Description
1 Central Control Monitor
System Configuration PC Card
Service Data PC Card
2 Monitor Mounting Arm
3 Roller Pump, 6 inch
Roller Pump, 6 inch, Gray
Cover-Hinge Assembly, 6 inch
4 Roller Pump, 4 inch
Roller Pump, 4 inch, Gray
Cover-Hinge Assembly, 4 inch
5 Centrifugal Control Unit
Centrifugal Control Unit, Gray
6 Centrifugal Drive Motor
Flexible Mounting Arm
Manual Drive Unit
7 Telescoping Pole
(1.3 inch (3,3 cm) diameter; 6 –7.5 feet
(1,8 – 2,3 m) in length
Mounting Pole (4 feet (1,2 m) in length)
Mounting Pole (3 feet (0,9 m) in length)
Mounting Pole (2 feet (0,6 m) in length)
Short Pole
8 Crossbar
9 Pole Collar
10 Crossbar Fitting
11 Solution Rack
Shelf (not shown)
12 Lamp, 33 inch (83,8 cm)
Lamp, 15 inch (38,1 cm)
13 Hand Crank Bracket
(includes 2 each hand cranks)
14 Roller Pump Pole Mount
Dual Pumps Pole Mount
Descending Pump Bracket
15 Centrifugal Unit Pole Mount
Roller Pump Mounting Extension, large
Roller Pump Mounting Extension, small
Sliding Back Cover Panel Kit
16 Modules
Air Bubble Detect Module
Air Sensor, 3/8 in. x 3/32 in.
Air Sensor, 1/4 in. x 1/16 in.
Air Sensor, 1/4 in. x 3/32 in.
Cable Assembly
Sensor Holder
Air Sensor Bracket
Level Detect Module
Alarm Sensor, Red
Alert Sensor, Yellow
REF
/Catalog No.
816300
803739
803740
801441
801041
816571
871928
801040
816570
871929
801046
816572
164267
816620
164268
16431701
16553401
131115
16553301
801407
16426
150826
145980
146819
816489
801238
801558
802089
801016
801093
816477
816483
804372
802523
802524
816370
802110
5773
5785
5791
822763
149876
5793
802111
195274
195215
12-19
