Central Control Monitor

Configure Pumps

Add Primary Pump

After selecting patient and pump orientation, the next step in creating a Perfusion
Screen is to add the primary pump.
The primary pump is the arterial pump.
Pump type, display units, reservoir type, pump name, and pump color are selected
from this screen.
All the selections must be made, or the defaults accepted, before continuing.
Select Pump Type choices
Configure Perfusion Screen > Add Primary Pump
To Add Primary Pump:
Select Pump Type:
Large Roller Pump
Small Roller Pump
Centrifugal Pump
Default Display Units L/min
Select Blood Reservoir Type:
Open
Closed
Display Units
choices for roller pump are:
{
L/min/m2
Primary Pump Only
mL/kg/min
Select Pump Type
Select the pump type by touching the appropriate name. The default selection is
Large Roller Pump.
Display Units
If roller pump is selected as the pump type, a unit of measure related to flow rate can
be chosen.
1. Touch the Default Display Units button until the desired unit of measure is
displayed.
• These units will be displayed on both the CCM and the roller pump display. The
default selection is L/min.
If a centrifugal pump is selected as the pump type, the display units default to RPM.
A centrifugal pump can be configured to display flow rates in L/min if a flowmeter is
added to the configuration and placed on the centrifugal pump icon. (See Add Flow
Sensor section for further details.)
Select Pump Name: Select Pump Color
Available:
Arterial
Selection
Select From List:
ART
Arterial
CPG
CPG1
CPG2
Vent
Vent1
Or Enter New Name:
Enter New Name >
< Previous Next >
Select Reservoir Type
L/min
RPM
4-56
Select Pump Name
CABG Roller
Assigned:
Select Pump Color
No
Cancel
