System Base
Lamp
The system lamp is an optional item. The lamp mounts to any of the system poles. It
connects to the system base for power and uses a 20 watt, 24 volt halogen bulb. The
lamp has a flexible shaft for easy positioning.
CAUTION: The lamp may get hot when powered on for extended durations. Do
not allow the lamp housing to touch the patient, user, perfusion circuit or other
equipment
To Mount a Lamp to the System Base:
1. Mount lamp bracket to pole.
2. Plug lamp into base receptacle.
3. Turn lamp On.
4. Position as needed.
The front portion of the lamp bracket and the front portion of the hand crank bracket
can be coupled into one system to reduce the number of brackets attached to the
poles.
On Switch
To base connector
Hand Cranks
Hand cranks should be positioned for easy access during emergency conditions.
To Mount the Hand Cranks to a Pole:
1. Mount hand crank bracket to pole.
2. Place hand cranks in the bracket slots.
3-19
