Additional Information
Safety Tab
The area of the Perfusion Screen used to operate safety systems including: air, level,
pressure, temperature, and flowmeter.
Scroll Button
A button or arrow used to scroll through the views for components of the same type,
one at a time.
Service Data Card
A PC card contained in one of the CCM card slots that stores system logs, module
logs, and Perfusion Screens and is used by authorized service personnel.
Service Screen
Service is a functional area of the Central Control Monitor that is used by Terumo
authorized service personnel to perform service functions. It is password protected.
Examples of functions that can be performed are: viewing the logs; exportation of
the system logs, module logs, and Perfusion Screens to an external computer via
the service data card, and viewing module error event data. It can also be used to
manage security access controls and view the system software version control area.
Servo Mode
Roller or centrifugal pump function that uses the feedback from a pressure transducer
or flowmeter to regulate the pump speed to maintain a constant pressure or flow rate.
Servo Setpoint
The target pressure or flow value to be maintained by a roller or centrifugal pump
operating in Servo mode.
Servo Source
A pressure transducer or flowmeter that is used to provide feedback information to a
roller or centrifugal pump. The pump speed is then regulated to maintain the servo
source set point constant.
Setup Tab
The area of the Perfusion Screen used to input patient information, view and modify
blending gas and low FiO alarm, view and modify pump and occluder responses,
2
view and modify timer types, and view and modify the time and date.
Slide Bar
A representation on the Perfusion Screen that allows the user to adjust pump speed,
FiO , total gas flow, and occluder % flow. The slide bar provides a method to make
2
large and small adjustments and displays the minimum, maximum, and current value
of the parameter being adjusted.
Small Roller Pump
The small roller pump has all the characteristics described for the large roller
pump, except it has a 4 inch (10 cm) raceway. It can be used for pediatric arterial,
cardioplegia, vent, or suction applications.
Stop Response
The reduction of the pump speed to zero and transition to Stop mode in response to
an event. The user must restart the pump.
