Terumo Advanced Perfusion System 1 Operator's Manual page 117

Central Control Monitor
The process of creating a Perfusion Screen involves adding and placing pumps and
devices, then creating and/or editing safety connections, and, finally, assigning the
physical pumps and devices to their graphical icons.
Note: If using TLink™ Data Management System software to collect data, device
names must be selected from the list of predefined names in order for the data to be
recognized by the software.
To Create a New Perfusion Screen Configuration
1. Touch the New button.
• From this first screen, choose a unique name for the Perfusion Screen, Select
Primary Pump Location and Patient Direction, or cancel the creation of a new
screen.
• This is the first of a series of screens the user must complete in order to
configure a Perfusion Screen.
2. Use the Next and Previous buttons to go back and forth between screens.
To Change Perfusion Screen Name:
The name of the Perfusion Screen appears in the upper right corner. A default name
is assigned to all new Perfusion Screens.
To change the default name:
1. Touch the Edit Name button.
2. Use the keyboard to enter a new name.
3. Touch Enter or OK.
To Create a New Perfusion Screen Configuration:
Select Primary Pump Location and Patient Direction:
Pump Left
Patient Left
Patient Right
Perfusion Screen Name:
SCREEN2
Pump Right
Edit Name >
Next >
4-54
Select Primary Pump
Location and Patient
Direction
Name The Perfusion
Screen
Touch Cancel to
Cancel
cancel creation of
a new perfusion
screen.
