System Base
18 monitoring modules; any combination of flow, temperature, pressure, level,
occluder, air bubble detect, and serial interface modules; all modules assigned and
activated;
1 Electronic Gas Blender module, connected and activated;
1 lamp; connected and activated;
1 Central Control Monitor; connected and activated.
WARNING: If a partially charged battery system is used, there may be less than
60 minutes of battery power available for a fully loaded system.
WARNING: Turn the system power off at the AC (Mains) power switch on the
system before inspection, cleaning, preparation for use, or storage in order to
turn off both the battery power and the AC (Mains) power.
WARNING: Charge the batteries monthly. Storage of a System 1 without charg-
ing the batteries monthly may damage the batteries and lead to overstated bat-
tery life. This damage, caused by a gradual discharge of the batteries, may cause
loss of battery backup without warning.
Battery charge level should be checked before each case.
The batteries must be fully recharged after storage, prior to use on a case. During stor-
age there is a gradual discharge of the batteries which may reduce the available battery
backup time. A power status indicator LED on the front panel of the base indicates the
status of the battery charge. When starting a system that has been in storage, allow at
least 1 minute to elapse after the CCM displays the Main Screen, before checking the
power status indicator LED.
On the Main Screen, the Power Source/Battery Status icon will display a color indicating
the approximate battery time available. In addition, charge level information can be found
within a Perfusion Screen. The Power Source/Battery Status icon will display a color indi-
cating the approximate battery time available. More information is available in the Power
subtab when a Perfusion Screen is open.
The batteries will charge, as needed, while the system is operating from AC (Mains)
power.
To recharge the batteries, the system must be plugged into the AC (Mains) power supply
with the AC (Mains) power switch turned on. It takes up to 13 hours to fully recharge the
batteries.
As the batteries recharge, the color of the power status indicator LED and Power Source/
Battery Status icon will change to indicate the condition of the batteries:
• Steady green indicates a battery system with one hour or more run time for a fully
loaded system;
• Steady red indicates a battery system with less than one hour run time for a fully
loaded system.
