Central Control Monitor
Assign Air Detectors, Level Detectors, Occluders, Flow Sensors, and CDI
Select device type.
Touch the Assign Devices button.
Assign Configuration Device to Physical Module: Air Detectors
1. On the base, locate the module with the green flashing light.
Assigned Device:
2. To assign a configuration device to a physical module:
Touch the device in the unassigned list, then touch the 'Assign' button.
Unassigned:
ART Air
3. To assign another Air Detector device:
Touch the 'Go to Next Module' button and repeat from step 1.
1. On the base, locate the module with the green flashing light.
If there is only one device of the type selected on the system base, there will
only be one module with a flashing light. If there is more than one device of the
type selected on the system base, touch the Go To Next Module button until the
desired module is flashing.
2. To assign a configuration device to a physical module, touch the device in
the unassigned list, then touch the 'Assign' button.
The device name will move from the Unassigned list to the Assigned list. The
device name also appears in the Assigned Device box in the top section of the
screen.
Devices that appear in the Assigned list may be unassigned by touching the
name of the device and then touching the Unassign button. The device name
moves from the Assigned list to the Unassigned list and disappears from the
Assigned Device box. In order to assign a device that has been previously
assigned to a different module, it must first be unassigned, and then reassigned.
3. To assign another device of the same type, touch the 'Go to Next Module'
button and repeat from step 1.
Continue until all devices of the same type on the graphic display have been
assigned to physical modules on the system base. Once the assignments are
complete, touch the OK button.
Go to Next Module
Assigned:
Assign > Assign >
< Unassign
< Unassign
OK
