Terumo Advanced Perfusion System 1 Operator's Manual page 101

Central Control Monitor
Priority Condition
Alarm Flow for flow sensor
placed on a centrifugal
pump has gone below
minimum limit.
FiO has dropped
2
below minimum limit.
O source pressure
2
< 30 psi or more than
18 psi below the air
pressure.
O source pressure
2
> 70 psi.
Air source pressure
< 30 psi or more than
18 psi below the O
2
pressure.
Air source pressure
> 70 psi.
95/5 source pressure
< 30 psi or more than
18 psi below the O
2
pressure.
95/5 source pressure
> 70 psi.
Over temperature
condition.
Primary pump internal
error detected.
Primary pump low level
motor faults cause the
pump to stop.
Alert Pressure has risen
above alert limit, but
below alarm limit.
Pressure has risen
above alert limit, but
below alarm limit.
Level sensor alert
sensor detects low
level.
CCM Display Message Operator Response
MINIMUM FLOW Correct low flow condition.
< Pump Name > Alarm clears automatically.
< Pump Response > Restart pump if stopped.
LOW FiO2 Increase FiO
minimum limit to clear alarm.
LOW OXYGEN SUPPLY Check O
PRESSURE O supply and switch source if
2
necessary.
HIGH OXYGEN SUPPLY Check O
PRESSURE source if necessary.
LOW AIR SUPPLY Check air hose connections. Check
PRESSURE air supply and switch source if
necessary.
HIGH AIR SUPPLY Check air supply pressure and switch
PRESSURE source if necessary.
LOW 95/5 SUPPLY Check 95/5 hose connections. Check
PRESSURE 95/5 supply and switch source if
necessary.
HIGH 95/5 SUPPLY Check 95/5 supply pressure and
PRESSURE switch source if necessary.
< Temperature Name > : Correct over temperature condition.
OVER TEMPERATURE Alarm clears automatically.
< Primary Pump Name > : Reassign pump, use standby
SERVICE PUMP equipment or use hand crank.
Discontinue use of the pump until it
has been serviced by Terumo
Cardiovascular Systems.
< Primary Pump Name > : Try to restart motor. If message
CHECK MOTOR reappears, either reassign pump or
use standby equipment. Discontinue
use of the pump until it has been
serviced by Terumo Cardiovascular
Systems Service.
< Pressure Name > : Monitor pressure. Check for
CHECK PRESSURE condition that could lead to pressure
alarm.
CHECK PRESSURE: Monitor pressure. Check for
< Pump Name > condition that could lead to pressure
< Pump Response > alarm.
< Level Detector Name > : Fill reservoir above alert level. Start
CHECK LEVEL pump if stopped. Alert clears
automatically.
4-39
setting to above
2
hose connections. Check
2
supply pressure, switch
2
