Roller Pump Messages - Terumo Advanced Perfusion System 1 Operator's Manual

Roller Pumps

Roller Pump Messages

Roller pump messages are displayed in the message area on the pump display.
There are five categories of pump messages.
Response to Messages Table
Message Type
External Alarm - A device or sensor that
is connected to the roller pump has
reported an alarm condition.
External Alert - A device or sensor that is
connected to the roller pump has reported
an alert condition.
Internal Alert – an alert condition related
to the roller pump has been detected.
Internal Error – a roller pump error
condition has been detected.
Internal Status – the status of a pump
condition has changed.
The following table includes the messages that can appear on the roller pump display
and corresponding operator responses.
Priority Condition
Alarm Air detected for
connected air bubble
detector.
Low level detected
for connected alarm
level sensor.
Alarm over pressure
detected for connect-
ed pressure sensor
Alert Connected pump has
stopped.
Connected pump has
started.
Connected roller pump
has paused.
Connected centrifugal
pump detects min flow.
Display
Reverse video, blinking, <Response>: <Message>
Possible displays:
• STOPPED: < Message >
• PAUSED: < Message >
• SLOWED: < Message >
• < Message > for Message Only
Reverse video, <Response>: <Message>
Possible displays:
• STOPPED: < Message >
• PAUSED: < Message >
• SLOWED: < Message >
• < Message > for Message Only
Reverse video, < Message >
Normal video, Blinking < Message >
Normal video, < Message >
Pump Display Message
< Response >: AIR DETECTED
< Response >: LOW LEVEL
< Response >: OVER PRESSURE Correct over pressure condition,
< Response >: PUMP STOP
< Response >: PUMP START
< Response >: PUMP PAUSE
< Response >: MINIMUM FLOW Restart pump if stopped.
5-27
Operator Response
Correct air condition, reset alarm,
restart pump if stopped.
Correct low level condition, restart
pump if stopped.
restart pump if stopped.
Restart connected pump,
restart pump if stopped.
Restart pump if stopped.
Restart pump if stopped.
