Central Control Monitor
Place the Pump
Select a place on the screen for the pump to appear.
Touch the white rectangle that corresponds to the desired location of the pump.
Change the placement position by touching any other blank rectangle. Choose the
Undo Place button to remove the pump from its place on the screen.
Choose Do Not Place and the pump will not be placed on the screen. Up to 6
pumps can be placed on the screen. A seventh pump can be added and not placed
if designated as the backup pump. A pump that has not been placed on the graphical
display has the label, Not Placed, next to its name in the Pumps list.
Configure Perfusion Screen > Configure Pumps
Menu
Configure Pumps
Configure Other Devices
Edit Safety Connections
Assign Devices to Modules
Pumps:
Arterial
Edit >
Add > Edit >
Place >
Place > Remove >
Remove >
Save As >
Close
Select the Next button to proceed to the next screen.
Note: When initially placing a designated cardioplegia pump, a window appears
asking if a safety connection between the primary pump and the cardioplegia pump is
desired. If the designation is edited, the window does not reappear.
Choose Yes and follow the steps to set up the safety connection. For more
information, see the section Edit Safety Connections in this chapter.
Choose No and no safety connection will be made at this time. A safety connection
between the arterial and cardioplegia pump may be set up at a later time.
Do you want to setup CPG pump to stop with Arterial?
To Place the Pump 'CPG',
Touch One of the Valid Location(s) Indicated Below:
Undo Place Do Not Place
Undo Place
Arterial
L/min
START
CPG
Arterial
Stop
Stop
Yes
4-63
CABG ROLLER
CABG
Pump
000:00
Reset
Reset
Clamp
000:00
Reset
Reset
< Previous Next >
Next >
No
