Additional Information
Symbol Title
REF
Catalogue Number
ON, circuit closed.
OFF, circuit open.
Do not turn upside down
START/STOP
Select
Manual
Servo Mode
Pulse Mode
M
Master Pump
F
Follower Pump
Centrifugal Pump
Air Bubble Detector, air bubble detec-
tion.
Level Detector, level detection.
Pressure Module
Description
Indicates the manufacturer's
catalogue number so that
the medical device can be
identified
ON, circuit closed.
OFF, circuit open.
Indicates not to turn the
Ultrasonic Air Sensor upside
down
START/STOP
Select
Manual
Servo Mode
Pulse Mode
Master Pump
Follower Pump
Centrifugal Pump
Air Bubble Detector, air
bubble detection.
Level Detector, level detection.
Pressure Module
