Central Control Monitor
View Summary
A summary is a text version of a Perfusion Screen. It contains information about the
screen name, graphic orientation, reservoir type, assigned devices, assigned pumps,
and enabled safety connections.
To view the summary of a Perfusion Screen
1. Touch the Perfusion Screen name.
2. Touch the View Summary button.
3. Select the Close button to return to the previous screen.
Rename
To rename a Perfusion Screen
1. Select the screen to be renamed.
2. Touch the Rename button.
3. Use the keyboard to enter the new name.
4. Touch OK or Enter to save the new name.
Delete
To delete a Perfusion Screen
1. Touch the Perfusion Screen name.
2. Touch the Delete button.
• A confirmation window will be displayed to allow the user to confirm or cancel the
deletion.
Are you sure you want to delete perfusion screen 'CABG'?
3. Choose Yes to delete the Perfusion Screen.
4. Touch No or Cancel to keep the Perfusion Screen in the system computer or on
the PC card.
Edit Card Name
To edit the name of a PC card:
1. Touch the Edit Card Name button.
2. Use the keyboard to edit the name.
3. Touch OK or Enter to save the new name.
To close the PC Card Utilities Screen and return to the Configuration Screen, touch
the Close button.
No
Yes Cancel
4-52
