Add An Occluder - Terumo Advanced Perfusion System 1 Operator's Manual

Central Control Monitor
Place the Level Detector
The available location for the level detector appears as a white square. Touch the
white square to place the level detector.
Arterial
Undo Place
Undo Place
Set Safety Connections
After a level detector is placed, the system automatically prompts the user to set a
safety connection for the level detector.
Connections are required between a level detector and the primary pump.
Choose Yes to set a safety connection. Choose No to defer setting a safety
connection.
Do you want to setup a safety connection for Level?
Primary Pump requires Level Detector Alert and Alarm Connections.

Add an Occluder

A maximum of 1 occluder is allowed on a Perfusion Screen.
1. Select Add.
2. Select Occluder as device type.
3. Name the occluder.
Gas % O2 FiCO2
0
0 0
Vent Sucker1 Sucker2
To Place the Device 'Level',
Touch One of the Valid Location(s) Above:
Do Not Place < Previous
?
Event Response
Yes
4-69
Pump
000: 00
Reset
Reset
Clamp
000: 00
Reset
Reset
CPG
Next >
Next >
No
