Terumo Advanced Perfusion System 1 Operator's Manual page 132

Central Control Monitor
Place the Air Sensor
Available locations for the air sensor appear as white squares on the screen. Place
the air sensor in the location that most closely matches the actual location of the air
sensor in the circuit by touching the appropriate white square.
Gas
Vent
Arterial
To Place the Device 'ART Air',
Touch One of the Valid Location(s) Above:
Undo Place Do Not Place
Undo Place
Change the location by touching any white square. Choose the Undo Place button
to remove the air sensor from its place on the screen.
Safety Connections
Do you want to setup a safety connection for ART Air?
Primary Pump requires at least one Air Detector Connection.
After an air sensor is placed, the system automatically prompts the user to set a
safety connection for the air detector.
At least one safety connection is required between an Air Bubble Detect module and
the primary pump. It is highly recommended that an Air Bubble Detection system be
used on the arterial line with a safety connection to the primary pump for every case.
Choose Yes to set up the safety connection; choose No to defer setting a safety
connection.
% O2 FiCO2
0
0
0
Sucker1 Sucker2 CPG
< Previous
?
Event Response
Yes
4-67
Pump
000: 00
Reset
Reset
Clamp
000: 00
Placing a device in this location
may interfere with a CDI display
icon.
Reset
Reset
Next >
Next >
No
