Central Control Monitor
Priority Condition
Status O calibration finished.
2
Warm up in progress.
O sensor exposure
2
limit reached.
Gas system warm up
complete.
The %O and the FiO
2
readings do not agree.
O Analyzer calibration
2
failed.
Flow sensor has become
disconnected from the
module.
CDI 100/101 disconnected No CDI 100 Data
or not all data being
detected.
CDI 500 disconnected
or not all data being
detected.
CCM Display Message
O2 Analyzer Calibration
Complete
Gas System Warming Up
Service O2 Sensor
Calibrate O2 Analyzer
Calibrate O2 Analyzer
2
Cannot Calibrate O2
Analyzer XX (may only
appear in Aux tab)
12 User pressed cancel
button.
13 Flow or FiO knob
2
turned during calibration
16 O Sensor is expired
2
17, 19 Blender mechanical
problem
18 Flow mechanical problem
20, 21, 22 Flow meter fault
23 O sensor fault
2
<Flow Sensor Name > :
Disconnected
No CDI 500 Data
4-46
Operator Response
Message displays for 10 seconds.
Message clears when warm up
is complete.
Backup analyzer should be used until
O sensor is replaced by Terumo
2
Cardiovascular Systems Service.
Perform O Analyzer calibration.
2
Inspect gas circuit for kinks, blockages,
or leaks. If necessary, use a backup O
analyzer.
Check status code.
Retry calibration. If calibration does
not pass, use backup until unit can be
serviced.
Reconnect flow sensor. Message
clears automatically.
Check CDI 100/101 settings and cable
connections. If message still appears,
contact Terumo Customer Service.
Check CDI 500 settings and cable
connections. If message still appears,
contact Terumo Customer Service.
