Central Control Monitor
Choose Undo Place to remove the pressure sensor from the Perfusion Screen.
Choose Next to continue.
Set Safety Connections
After a pressure sensor is placed, the system automatically prompts the user to set
a safety connection. Alert and alarm safety connections are required between a
pressure sensor and the primary pump.
Choose Yes to set a safety connection.
Choose No to defer setting a safety connection.
Do you want to setup a safety connection for ART Pres?
Primary Pump requires Pressure Sensor Alert and Alarm Connections.

Add Flow Sensors

A maximum of 4 flow sensors is allowed in a Perfusion Screen.
1. Select Add.
2. Select Flow Sensor as device type.
3. Choose name from the list or choose Enter New Name and use the keyboard to
enter a device name.
To Add Device:
Select Device Type:
Air Detector
Level Detector
Occluder
Pressure Sensor
Flow Sensor
Temperature Sensor
CDI 100
CDI 500
Current defined: 0
Maximum allowed 4
?
mmHg
Event Response
Yes
Select Device Name:
Art Flow
Select From List:
Art Flow
VEN Flow
CPG Flow
FLOW1
FLOW2
Or Enter New Name:
Enter New Name >
Next >
4-73
No
Cancel
