Note: When reassigning pumps, verify all operating parameters after
reassignment, including tube size or flow constant, direction, and display units.
Select No to return to the previous screen.
Module Info Subtab
Information about each module that is online can be displayed using the Module Info
subtab. This information can assist in determining whether operating parameters for
the module or pump are within operating range.
For each online module the following information will be displayed:
Module ID:
Software Revision:
Self Test Result: Pass/Fail
Operation Status: Pass/Fail
V5 Voltage (mV): and Pass/Fail Status
V5 Current (mA): and Pass/Fail Status
Vmot Voltage (mV): if applicable and Pass/Fail Status
Vmot Current (mA): if applicable and Pass/Fail Status
Temperature (degrees C): and Pass/Fail Status
Total Volume (mL): total volume delivered for selected roller pump
System
Module Type:
Settings
Air
Power Sensor
Module Name:
Reassign
Module
ART Air
Module Info
System
Module Type:
Settings
Large Roller Pump
Power
Module Name:
Reassign
Module
Arterial
Module Info
A failure of the self test or operational status indicates the module or pump is not
functioning properly and should be replaced. Values not applicable to a specific
device will post an N/A in the Pass/Fail column.
Module ID: 00012 Software Revision:
Self Test Result: PASS Operation Status:
V5 Voltage (mV): 5084 PASS
V5 Current (mA): 110 PASS
Vmot Voltage (mV): 22915 PASS
Vmot Current (mA): 80 PASS
Temperature ( C): 37.2 PASS
Module ID: 00019
Software Revision:
Operation Status:
Self Test Result: PASS
V5 Voltage (mV): 5020 PASS
V5 Current (mA): 293 PASS
Vmot Voltage (mV): 23871 PASS
Vmot Current (mA): 176 PASS
Temperature ( C): 30.0 PASS
Total Volume (mL): 6710
