System Base
Central Control Monitor Power Source/Battery Status Icon (only displayed on the
Main and Perfusion Screens) – Provides information about battery life as follows:
When operating from AC (Mains) Power:
• Steady green indicates a battery system with greater than one hour run time
with a fully loaded system
• Steady red indicates a battery system with less than one hour run time with a
fully loaded system
When operating from the battery system:
• The approximate battery life in minutes is displayed above the Power Source/Battery
Status icon
• The color of the Power Source/Battery Status icon will change as the estimated
remaining capacity in minutes decreases:
• Flashing green indicates 30 minutes or more battery life at present discharge rate
• Flashing yellow indicates 15 minutes or more, but less than 30 minutes battery life
at present discharge rate
• Flashing red indicates less than 15 minutes battery life at present discharge rate.
The time displayed above the Power Source/Battery Status icon, the color of the
icon, and the available capacity in minutes in the Power subtab within the System tab
should only be used as approximations of the amount of time remaining.
Power subtab within the System tab (only displayed on the Perfusion Screen) -
Contains a summary of the power information for the system. See the
Central Control Monitor section, Power Subtab for further details.
System
Settings
Power
Estimated Battery Time Remaining (min): 82
Reassign
Module
Module Info
The Battery Charge Level found in the Power subtab within the System tab provides
a bar graph indicating the approximate charge status of the battery.
• Power Source - AC power or battery.
• AC Power Capacity Used - Indicator of power consumption when using AC power.
• Estimated Battery Time Remaining - Provides an estimated remaining battery
backup time, regardless of current Power Source.
Note: This will be the same time estimate as shown over the Power Source/Bat-
tery Status icon when on battery backup.
• Battery Charge Level - Provides a bar graph indicating the charge status of the
battery.
In summary, if the system is operating from batteries, the Power Status Indicator
LED will flash. If the system is operating from batteries and if a Perfusion Screen is
opened, a message is displayed in the message area of the CCM and in the Messages
53 min
AC (Mains) Power
Indicator
53 min
On Battery Indicator
Power Source: AC Power
AC Power Capacity Used: 11.8 %
Battery Charge Level:
