Terumo Advanced Perfusion System 1 Operator's Manual page 303

Technical Support
Variable Names
Each configured device in System 1 has a set of periodic data or events that it
provides to the data transfer module. Each of the System 1 devices is listed in
the following sections with the specific periodic data and event information that is
transmitted from the data transfer module.
ABD
Mnemonic Description
ABAM Air bubble detected alarm
ABMC Air bubble alarm cleared
CDI 100 (device name is "CDI 100")
Mnemonic Description
SAT Oxygen Saturation
HCT Hematocrit
HB Hemoglobin
CDI 500 (device name is "CDI 500")
Mnemonic Description
A_PH Arterial pH
A_CO Arterial PCO2
A_O2 Arterial PO2
A_TM Arterial Temperature
A_SO Arterial Oxygen
Saturation
A_HC Arterial Bicarbonate
A_BE Arterial Base Excess
K+ Potassium
VO2 Oxygen Consumption
V_PH Venous pH
V_CO Venous PCO2
V_O2 Venous PO2
V_TM Venous Temperature
V_SO Venous Oxygen
Saturation
HCT Hematocrit
HGB Hemoglobin
V_HC Venous Bicarbonate
V_BE Venous Base Excess
These values are all left justified within a 4-character field. The fifth character of the value has a space, "L", "H", or "A"
1
character. The space indicates normal analyte status; the "L" indicates a Low alarm status; and the 'H' indicates a High alarm
status. The "A" indicates actual value.
Value Units
Value Units
0 to 100 %
0 to 100 %
0.0 to 100.0 g/dL
Value Units
1
6.8 -8.0
10 - 80, 1 - 11 mmHg, kPa
10 - 500, 1 - 67 mmHg, kPa
10 - 45 C
60 - 100 %
0 - 50 mEq/L
-25.0 to +25.0 mEq/L
1.0 - 8.0 mmol/L
10 - 400 mL/min
6.8 - 8.0
10 - 80, 1 - 11 mmHg, kPa
10 - 500, 1 - 67 mmHg, kPa
10 - 45 C
60 - 100 %
15 - 45 %
5-15 g/dL
0-50 mEq/L
-25.0 to +25.0 mEq/L
11-8
Part of
Type Snapshot?
Safety Event
Safety Event
Part of
Type Snapshot?
Periodic Yes
Periodic Yes
Periodic Yes
Part of
Type Snapshot?
Periodic Yes
Periodic Yes
Periodic Yes
Periodic Yes
Periodic Yes
Periodic Yes
Periodic Yes
Periodic Yes
Periodic Yes
Periodic Yes
Periodic Yes
Periodic Yes
Periodic Yes
Periodic Yes
Periodic Yes
Periodic Yes
Periodic Yes
Periodic Yes
