Central Control Monitor
View Summary
The summary screen displays information about the defined
configuration for that Perfusion Screen. The name of the Perfusion
Screen, graphic orientation, type of venous reservoir, devices included
in the Perfusion Screen, and the assigned names of the devices are
displayed. Also included is information about the pumps, such as type,
name, and any safety connections between the pumps and the other
configured devices.
To view a Perfusion Screen Summary:
1. Touch the Perfusion Screen name. The selected screen will be
highlighted.
2. Touch the View Summary button to view a summary of the screen.
3. Select the Close button to return to the previous screen.
Screen Name
Perfusion Screen Summary
Graphic Orientation:
Primary Pump Left - Patient Head Left
Blood Reservoir Type:
Open
Air Detectors:
ART Air
Level Detectors:
Level
Occluders:
Occluder
Pressure Sensors:
ART Pres
CPG Pres
Temperature Sensors:
ART Temp
VEN Temp
Bladder
CPG1 Temp
CDI 500:
CDI 500
Large Roller Pumps:
Arterial
CPG
Small Roller Pumps:
Vent
Sucker 1
Sucker 2
Timers:
Pump
Clamp
TMR1
To Return to Main:
Touch the Return to Main button to return to the Main Screen.
