Roller Pumps

Sliding Back Cover Panel Kit

If a full complement of pumps is not installed across the width of the base, the
opening to the cable management area is exposed in each vacant pump space. To
cover this opening, protect the area from dust and spills, and hide the wiring and
cabling from view, use the appropriate sized cover from the Sliding Back Cover Panel
Kit.
To install a sliding back cover panel:
1. Remove the cable cover.
2. Remove the module cover from the side of the base closest to the empty pump
space.
3. Loosen the set screws on the endcap. Some modules may need to be removed
to access the set screws.
4. Slide the endcap out.
5. Slide the 2 rail slides onto the mounting rail.
6. Position the appropriate sized cover panel on the rail slides. Secure the cover
panel to the rail slides with the 2 screws.
7. Install the set screw through the cover panel and rail slide to secure the cover
panel to the mounting rail.
8. Slide the endcap back into position and tighten the set screws. Install any
removed modules.
9. Install the module cover and the cable cover.
If the empty space occurs between pumps, the pumps may need to be removed in
order to install a cover panel into the appropriate place.
