Perfusion Screen - Terumo Advanced Perfusion System 1 Operator's Manual

Central Control Monitor

Perfusion Screen

The Perfusion functional area is used to select and run a perfusion case.
Touch the Perfusion button to go to Choose a Perfusion Screen.
The screen lists all Perfusion Screens by name and indicates whether the screen is
password protected. All screens that are password protected require the password to
be entered before the screen will display graphically on the CCM.
The user has three options from this screen:
1. View a summary of a Perfusion Screen.
2. Return to the Main Screen.
3. Open a Perfusion Screen.
Choose a Perfusion Screen
Name
CABG Roller
CABG Centrif
Min AVR
Circ-ARREST
Pediatric
Password:
Yes
Yes
No
Yes
No
4-10
Open
View Summary >
Return to Main
