Aux Tab - Terumo Advanced Perfusion System 1 Operator's Manual

Central Control Monitor
To Reset Auto Dose Selection:
Make sure the cardioplegia pump is stopped or that the Manual button is selected.
Otherwise, the button text will be gray indicating that the Auto Dose value cannot be
reset.
1. Touch the Reset button.
• The value set in the Auto Dose Setup subtab for the selected Auto Dose appears
to the left of the Reset button.
• An additional dose can now be delivered and automatically stop the pump.

Aux Tab

The Aux tab has two subtabs: Timers and Messages.
Timers Subtab
Timers, other than Pump and Clamp, are controlled through the Timers subtab. To
change the start value of a count down timer, use the Timers subtab within the Setup
tab.
Aux
Timers
TMR1
000: 00
Messages
Reset
To start the timer:
1. Touch the black box.
• The start time appears on the left side of the button.
TMR1
000:08
10:16
Reset
To stop the timer:
1. Touch the black box again.
• The stop time appears on the right side of the timer display.
TMR1
000:21
10:16 10:17
Reset
To resume the timer:
1. Touch the black box again.
• The timer continues counting.
• The resume time appears on the left side of the button.
16:07:51
4-30
