Roller Pumps
Ending Continuous Mode
Pressing the Stop button on the CCM or the Start/Stop button on the front panel will
stop the pump.
WARNING: Always check the pump for proper operational mode after a Pause
or Reduce Speed response has been executed. A pump may go to Stop mode
and need to be started manually if the pump has received multiple high priority
messages.

Pulse Mode

When using Pulse mode during a case, monitor the patient waveform on the
operating room monitor. The use of the term "Pulse mode" refers to the variable
pressure and flow waveforms that result from the cyclic operation of the primary
pump. Replication of a physiologic pulse from a natural heart is not obtained with a
pump speed controller. No claim of clinical benefit from the use of the Pulse mode
has been reviewed by global Regulatory Agencies.
A pulse cycle consists of one high speed period (Peak) and one low speed period
(Base). The high speed is controlled by the pump speed control knob or the pump
control slide bar CCM and the low speed is determined by the Base setting. The high
speed is displayed on the slide bar and the average speed is displayed in the pump
control box and the pump local display. The amount of time the pulse cycle is at the
high speed is determined by the Width setting. The Rate defines how many pulse
cycles will occur per minute.
Pulse Parameters
The Rate, Base, and Width must be set up using the CCM:
Note: Changes to the Width and Rate are initiated after the new value is stored.
Changes to the Base are sent as the value is changed.
1. Touch the Primary Pump icon to access the Primary Pump tab
2. Select the Pulse subtab
Arterial
Summary
100%
Servo
50%
Pulse
To Set the Rate
1. Touch the Rate button.
2. Use the large arrows to change the Rate in increments of 10 beats per minute.
3. Use the small arrows to change the Rate in increments of 1 beat per minute.
4. Touch the Rate button again to store the new value.
To Set the Base
1. Touch the Base button.
2. Use the large arrows to change the Base in increments of 10%.
3. Use the small arrows to change the Base in increments of 5%.
4. Touch the Base button again to store the new value. The recommended
minimum Base is 30%.
Pulse Control:
60 BPM
Rate:
65%
Base:
Auto Auto
Manual
Width: 50%
5-21
