Terumo Advanced Perfusion System 1 Operator's Manual page 94

Central Control Monitor
Power Subtab
This subtab indicates the power sources currently in use, the % of AC power in use,
an estimate of remaining battery time, and a graphical display of battery charge level.
System
Settings
Power
AC Power Capacity Used:
Estimated Battery Time Remaining (min): 82
Reassign
Module
Module Info
The Power Source is displayed as AC Power
SHUTDOWN if the batteries are depleted and the system is about to shutdown
completely. The AC Power Capacity Used is displayed in % if on AC and dashed
out if on battery. This is an indicator of the power consumption. If the system power
need approaches the limit of available power, the message, "Power System at 80%
Capacity" is displayed on the CCM to alert the user.
The Battery Charge Level is displayed as a bar graph to indicate charge status of the
battery.
Reassign Module Subtab
If a pump or module is broken, missing, or not communicating, use the Reassign
Module function to replace the device. A reassigned device takes on the role of the
broken device including icon control from the Perfusion Screen, all alert and alarm
limits, and all safety connections.
Note: When a module/pump has been reassigned, it replaces the original module
only for the duration of the case. If this reassigned module is a permanent
replacement for the original module, it should be assigned to the system from the
Configuration area. If it is not assigned to the screen through the Configuration area,
the device icon will display a "?" each time the Perfusion Screen is opened and the
module will need to be reassigned before it can be used.
System
Module Type:
Settings
Air Sensor
Power
Module Name:
Reassign
Module
ART Air
Module Info
1
AC power refers to AC (Mains) power.
Power Source: AC Power
11.8 %
Battery Charge Level:
1
, Battery, or SYSTEM POWER
Select Replacement
Offline Air Sensor
4-32
16:07:51
16:07:51
Reassign Reassign
Module
Module
