Terumo Advanced Perfusion System 1 Operator's Manual page 112

Central Control Monitor
Configuration Password
Assigning a configuration password restricts user access to the Configuration area.
1. Touch the Edit Config Password button to set a password.
2. Use the keyboard to enter a password.
3. Touch OK or Enter to save password.
PC Card Utilities
To save a copy of a Perfusion Screen to a PC card, touch the PC Card Utilities button.
This enables the user to back up Perfusion Screens and transfer Perfusion Screens
from one System 1 to another. It is recommended that Perfusion Screens be backed
up when they are first configured, when changes are made, and prior to having the
System 1 serviced. The user can also view Perfusion Screen summaries, rename or
delete Perfusion Screens, and rename PC cards.
To access the PC Card Utilities screen, touch the PC Card Utilities button.
• If a PC card is installed, the Accessing PC Card and Building PC Card List
windows will be displayed. Do not remove card when the Accessing PC Card or
Building PC Card List windows are displayed.
Perfusion Screens stored
on the PC Card
PC Card Utilities
Sample
Card:
Name: Ready: Ready: Last Edit:
Name:
Edit Card Name > >
The PC Card Utilities Screen will be displayed. The card name is displayed. A list
of all Perfusion Screens that are stored on the PC card is displayed on the left under
Card while all Perfusion Screens that are stored on the CCM is displayed on the
right under System Computer. A Yes or No in the Ready column of the list indicates
whether that particular Perfusion Screen is ready for use or not. The date in the Last
Edit column shows the last time the Perfusion Screen was edited.
Accessing PC Card
Do Not Remove PC Card
Utilities Buttons
PC Card Name
Last Edit:
Name:
Move > > Move > >
CABG Roller
CABG Centrif
< < Move
Min AVR
Copy > >
Copy > >
Circ-ARREST
Pediatric
< < Copy
View Summary >
Rename >
Delete
4-49
System Computer
Ready: Last Edit:
Yes 05/15/2002
Yes 05/15/2002
Yes 05/15/2002
Yes 05/15/2002
Yes 05/15/2002
Close
Perfusion
Screens
stored on
the CCM
