Terumo Advanced Perfusion System 1 Operator's Manual page 135

Central Control Monitor
Select a Color
The color chosen for the occluder appears in the control slide bar for the occluder.
There are two color choices.
1. Touch the desired color. The default color selection is blue.
2. Touch Next to continue.
To Add Device:
Select Device Type:
Air Detector
Level Detector
Occluder
Pressure Sensor
Flow Sensor
Temperature Sensor
CDI 100
CDI 500
Current defined: 0
Maximum allowed 1
Place the Occluder
The available location for the occluder appears as a white square.
Touch the white square to place the occluder.
Arterial
Undo Place
Undo Place
Select Device Name:
Select From List:
Occluder
VEN Occl
ART Occl
CPG Occl
OCCL1
Or Enter New Name:
Enter New Name >
Gas % O2 FiCO2
0
0 0
Vent Sucker1 Sucker2
To Place the Device 'Occluder',
Touch One of the Valid Location(s) Above:
< Previous
Do Not Place
4-70
Select Occluder Color:
Available: Assigned:
No
Selection
Next > Cancel
Pump
000: 00
Reset
Reset
Clamp
000: 00
Reset
Reset
CPG
Next >
Next >
