Modules

Features

Modules are the physical devices that connect safety and monitoring systems to the
Terumo ® Advanced Perfusion System 1. There are 9 types of modules that connect to
the system base and they are held in place with the module bracket system. Module
types and the maximum number of modules that can be used in a Perfusion Screen are:
Module Types
Air Bubble Detection
Level Monitoring
Pressure Monitoring
Temperature Monitoring
Flow Monitoring
Occluder
CDI 100/101 or 500
Data Transfer RS-232
Although modules look similar and have identical connectors for attaching to the base
(except the flow module), each module has specific software and unique connectors
which enables it to communicate with and attach to its intended device or sensor.
Each module is labeled so it can be identified while it is attached to the system base
and has a tricolor LED above the label that indicates its operational status.
The LED will display green, red, or yellow indications as follows:
• Constant Green – Online Mode
• Blinking Green – Assignment Mode
• Constant Yellow – Offline Mode
• Blinking Yellow – Alert Condition
• Constant Red – Broken Mode
• Blinking Red – Alarm condition
Before opening a Perfusion Screen, the module LED will cycle green, yellow, red,
then will remain constant yellow in Offline Mode. When a Perfusion Screen is opened
and the module is recognized as part of the case, the module enters Online mode
and the LED displays constant green.
If the Power-On Self-Test fails, a message is displayed at the top of the Main Screen
and the LED will either display constant red or will continuously cycle through the
colors. To verify a module is broken, connect the module to another base receptacle
and allow the Power-On Self-test to run again. If the module fails again, replace the
module. A broken module will display a red X on the device icon when a Perfusion
Screen is opened on the Central Control Monitor (CCM).
CAUTION:
Do not touch the module connector pins as static electricity and
moisture may damage the module circuitry and pins.
CAUTION:
Check the connectors for damage before use. Do not use a module
if damaged or bent connector pins are found.
CAUTION:
Do not use extension cords to connect the modules to the system.
Use of extension cords may compromise performance.
CAUTION:
Use only the cables provided to connect flowmeter modules to
the system.
Maximum
4
1
4
4
4
1
1
1
