Central Control Monitor
Select Pump Type
1. Select the pump type. The default selection is Large Roller Pump. The number
of pumps currently defined and the maximum number of pumps allowed is
displayed. Select pump type before making other selections on this screen.
Select Display Units
If the pump type selected is a roller pump, choose a display unit related to flow rate.
1. Touch the Default Display Units button until the desired unit of measure is
displayed. The default selection is L/min.
If the pump type selected is a centrifugal pump, the display units default to RPM. A
centrifugal pump can be configured to display flow rates in L/min if a flowmeter is
added to the configuration and placed on the centrifugal pump icon. (See Add Flow
Sensors section for further details.)
Select Pump Type Menu
To Add Pump:
Select Pump Name
Pump Designation
Select Pump Type:
Large Roller Pump
Small Roller Pump
Large Master Roller Pump
Small Master Roller Pump
Centrifugal Pump
Default Display Units L/min
Current defined: 1
Maximum allowed 6
Cardioplegia Pump
No
Backup Pump
No
Select Display Units Button
choices are:
L/min
RPM
Select Pump Name:
Select From List:
ART
CPG
CPG1
CPG2
Vent
Vent1
Vent2
Or Enter New Name:
Enter New Name >
4-59
Select Pump Color
Available: Assigned:
No
Selection
Arterial
Next > Cancel
