Roller Pumps

System Connection

Route and arrange the pump cable to minimize exposure to spills. With a clear view
of the desired pump or module connection, carefully connect the pump cable to one
of the system pump connections on either side of the system base or, if necessary,
to any of the system module connections. Do not use excessive force to seat the
connector and make sure not to bend the connector pins. Tighten screws to secure
the connection.
Standoffs are included in the accessories kit. Two standoffs must be installed on
a module receptacle to securely fasten a pump cable or a flowmeter cable to the
module receptacle. Only a pump power cable or flowmeter power cable can be
inserted into a receptacle which has the standoffs installed. Modules cannot be
inserted into a module receptacle when standoffs are installed.
