Starting System; Checking - wsm L503 Workshop Manual

L3130 · L3430 · L3830 · L4630 · L5030, WSM

[3] STARTING SYSTEM

(1) Checking

(A) Main Switch (ROPS Type)
Brake Lamp Switch Continuity
1. Disconnect the connector, and measure the resistance with an
ohmmeter between connector terminal.
2. If the measurement differs from the table below, the brake switch
is faulty.
When brake pedal is
Resistance
released
between connecter
When brake pedal is
terminals
depressed
(1) Brake Lamp Switch
Remove the Main Switch
1. Remove the combination switch.
2. Remove the panel cover.
3. Disconnect the main switch connector.
4. Perform the following checking.
(1) Main Switch
Connector Voltage
1. Measure the voltage between the terminal B and chassis.
2. If the voltage differs from the battery voltage (11 to 14 V), the
wiring harness is faulty.
Voltage Terminal B – Chassis
A : Wire Harness Side Connector 4C
9-S33
ELECTRICAL SYSTEM
Infinity
0 Ω
(2) Brake Lamp Switch Connector
W1024163
W1013848
Approx. battery voltage
W1014366
KiSC issued 02, 2007 A
