[3] CONTROL SYSTEM

(1) Basic Control System

(A) Normal Display
Proce-
Display Item
dure
Normal Display 1
1 Hour Meter
(Multiplication hours)
Normal Display 2
2
Trip Meter (Unit hours)
Normal Display 3
3
Traveling Speed (mph)
Normal Display 4
4
Traveling Speed (km/h)
Normal Display 5
PTO Speed
(PTO OFF)
5
(PTO ON)*1
6 Return to Top
NOTE
• Trip meter can be reset to 0.0 h by pushing and holding the display mode switch for about two seconds
with trip meter displayed.
*1 : Let's suppose that the PTO gear shift lever is at the neutral position. When you turn ON the PTO clutch
control lever, the PTO shaft stays off but the meter displays the rpm at the L position. This is normal, not
a machine failure.
liquid crystal display (LCD) while the main switch is
turned ON or the engine is starting.
always displayed on a right edge of LCD, and the
position of gear shifting is displayed on a left edge for
GST and HST model.
to five kinds of displays shown in the table below.
(1) IntelliPanel (Electronic
(2) Liquid Crystal Display (LCD)
(3) Display Mode Switch
(4) Travel Speed Switch
(5) Periodic Service Required
Manual Transmission Model
9-M18
The normal display is a message indicated in the
The fuel gauge and coolant temperature gauge are
By pushing the display mode switch (3), it is switched
Instrument Panel)
Readout
GST Model
ELECTRICAL SYSTEM
(6) Fuel Gauge
(7) Selected Speed Indication
(HST and GST Model Only)
(8) Message Display
(9) Unit Indication
(10) Coolant Temperature Gauge
W1017233
HST Model
W1015278
