9A-7 Wiring Systems:

Wiring Harness Routing Diagram

"D"
1
1. Wiring harness No. 2
2. Tapping clamp
: Insert the clamp from the front side. Place the turn signal
and position light couplers in front of the clamp.
3. Steel clamp
: Clamp the wiring harness at the blue taping point. Bend
the steel clamps to the front side.
4. Clamp:
Face the clamp end upward.
"A": Take care not pinch the position light lead wires between
the headlight assembly and cowling brace.
email: info@motomatrix.co.uk / www.motomatrix.co.uk
1
"C"
4
"E"
"F"
"B": Pass the left position light lead wires under the wiring harness No. 2.
"C": Route the steering damper lead wire under the wiring harness No. 2.
Do not pass it over the harness.
"D": Pass the wiring harness No. 2 in front of the air intake pipe mounting
fastener.
"E": Place the small coupler inside and the big one outside.
"F": Pass the right handlebar switch lead wire above the ignition switch
lead wire.
"A", "B"
2
3
B947H19102002
"A"
I947H1910907-03
