1A-30 Engine General Information and Diagnosis:
Step
1 1) Turn the ignition switch OFF.
2) Lift and support the fuel tank. Refer to "Fuel Tank
Removal and Installation" in Section 1G (Page 1G-9).
3) Remove the air cleaner box. Refer to "Air Cleaner Box
Removal and Installation" in Section 1D (Page 1D-7).
4) Check the CMP sensor coupler (1) for loose or poor
contacts.
If OK, remove the CMP sensor. Refer to "CMP Sensor
Removal and Installation" in Section 1C (Page 1C-2).
1
5) Connect 3 new 1.5 V batteries in series, 1 kΩ resistor
and the multi-circuit tester as shown in the figure.
Special tool
: 09900–25008 (Multi circuit tester set)
Tester knob indication
Voltage ( )
W
email: info@motomatrix.co.uk / www.motomatrix.co.uk
Action
I947H1110010-01
(–) (+)
1 kΩ
Bl/Y
B/Bl
I823H1110005-04
Yes
• B/Y, R or B/Br wire • Inspect that metal
open or shorted to
ground.
• Loose or poor
contacts on the CMP
sensor coupler or • If there are no metal
ECM coupler
(Terminal "7", "8" or
"35").
• If wires and
connection are OK,
intermittent trouble or
faulty ECM.
• Recheck each
terminal and wire
harness for open
circuit and poor
connection.
• Replace the ECM
with a known good
one, and inspect it
again.
No
particles or foreign
material stuck on the
CMP sensor and
camshaft tip.
particles and foreign
material, then replace
the CMP sensor with
a new one.
