4A-2 Brake Control System and Diagnosis:

Rear Brake Hose Routing Diagram

(a)
4
(f)
1. Hose clamp
: Face the clamp end backward.
2. Stopper
: After the brake hose union has contacted
to the stopper, tighten the union bolt.
3. Brake pad pin
4. Plug
5. Caliper sliding pin B
6. Caliper sliding pin A
email: info@motomatrix.co.uk / www.motomatrix.co.uk
2
(g)
5
"C"
"A": White marking
"B": Yellow marking
"C": Pass the reservoir hose above the brake hose.
: 23 N⋅m (2.3 kgf-m, 16.5 lbf-ft)
: 10 N⋅m (1.0 kgf-m, 7.0 lbf-ft)
: 27 N⋅m (2.7 kgf-m, 19.5 lbf-ft)
1
(c)
B947H14102002
(a)
2
"B"
"A"
(e)
3
6
(d)
I947H1410047-04
: 12 N⋅m (1.2 kgf-m, 8.5 lbf-ft)
: 17 N⋅m (1.7 kgf-m, 12.5 lbf-ft)
: 2.5 N⋅m (0.25 kgf-m, 2.0 lbf-ft)
: 6 N⋅m (0.6 kgf-m, 4.5 lbf-ft)
(b)
(e)
