APPENDIX E
Cable and Wire Specifications and Pinouts
for the TX Matrix Router

TX Matrix Management Port Cable Specifications

Related
Documentation
Copyright © 2010, Juniper Networks, Inc.
TX Matrix Management Port Cable Specifications on page 345
RJ-45 Connector Pinouts for the TX Matrix Management ETHERNET Port on page 346
DB-9 Connector Pinouts for the TX Matrix Management AUXILIARY and CONSOLE
Ports on page 346
TX Matrix Alarm Relay Contract Wire Specifications on page 347
For management and service operations, you connect the Routing Engine to an external
console or management network through ports on the corresponding TX-CIP.
Table 39 on page 345 lists the specifications for the cables that connect to management
ports.

Table 39: Cable Specifications for Routing Engine Management Interfaces

Cable
Port Specification
Management RS-232
console or (EIA-232) serial
auxiliary cable
interface
Management Category 5 cable
Ethernet or equivalent
interface suitable for
100Base-T
operation
TX Matrix Connector Interface Panel (TX-CIP) Overview on page 38
RJ-45 Connector Pinouts for the TX Matrix Management ETHERNET Port on page 346
DB-9 Connector Pinouts for the TX Matrix Management AUXILIARY and CONSOLE
Ports on page 346
Cable/Wire Maximum
Supplied Length
One 6-ft 6 ft (1.83 m)
(1.83-m) length
with DB-9/DB-9
connectors
One 15-ft 328 ft (100 m)
(4.57-m) length
with
RJ-45/RJ-45
connectors
TX Matrix
Router
Receptacle
DB-9 male
RJ-45
autosensing
345
