TX Matrix Routing Engine Description

Related
Documentation
26
The Routing Engine in the TX Matrix router maintains the routing tables used by the
routing matrix and controls the routing protocols that run on the routing matrix. The
TX Matrix router provides all routing tables, along with updates, to each T640 router in
the routing matrix.
You can install one or two Routing Engines in the TX Matrix router. The Routing Engines
install into the upper rear of the chassis in the slots labeled
Engines are installed, one functions as the master and the other acts as the backup. If
the master Routing Engine fails or is removed, and the backup is configured appropriately,
the backup restarts and becomes the master.
NOTE: We recommend that you run the same Junos OS release on the master
and backup Routing Engines. If you elect to run different Junos OS releases
on the Routing Engines, a change in Routing Engine mastership can cause
one or all T640 routers to be logically disconnected from the TX Matrix router.
Each Routing Engine requires a TX-CB to be installed in the adjacent slot.
below , and installs above
CB0 RE1
is present in the adjacent slot.
The ports for connecting the Routing Engine to external management devices are located
on the corresponding TX-CIP. The ports on
slot , and the ports on
RE0
The TX Matrix router supports the following Routing Engines:
RE-600-2048 (EOL)
RE-1600-2048 (EOL)
RE-A-2000-4096
NOTE: For specific information about Routing Engine components (for
example, the amount of DRAM), issue the
command.
TX Matrix Routing Engine Functions on page 6
TX Matrix RE-600 Description on page 27
TX Matrix RE-1600 Description on page 28
TX Matrix RE-2000 Description on page 30
. A Routing Engine does not power on if no TX-CB
CB1
TX-CIP-0
connect to the Routing Engine in slot
TX-CIP-1
and . If two Routing
RE0 RE1
installs
RE0
connect to the Routing Engine in
.
RE1
show chassis routing-engine
