TX Matrix Hardware Guide
Related
Documentation

TX Matrix RE-1600 LEDs

Related
Documentation

TX Matrix RE-2000 Description

30
Reset button—Reboots the Routing Engine when pressed.
LEDs— and
HD Slot LEDs 0 and 1
NOTE: The LEDs on the Routing Engine do not necessarily indicate
routing-related activity.
NOTE: The LEDs that report host module status (including Routing Engine
status) are on the craft interface rather than the Routing Engine faceplate.
TX Matrix Routing Engine Description on page 26
TX Matrix RE-1600 LEDs on page 30
TX Matrix Host Subsystem LEDs on the Craft Interface on page 37
Table 6 on page 30 describes the functions of these LEDs.

Table 6: RE-1600 LEDs

Label Color
HD Yellow
Red and
Slot LEDs 0
Green
and 1
alternately
Green
TX Matrix Host Subsystem Description on page 25
TX Matrix RE-1600 Description on page 28
TX Matrix Host Subsystem LEDs on the Craft Interface on page 37
The RE-2000 boots from the storage media in this order: the USB device, then the
CompactFlash card (if present), then the hard disk, then the LAN.
— indicate activity on the hard drive or PC Cards.
State Description
On steadily or Indicates activity on the hard drive.
blinking
Blinking Indicates that the Routing Engine is booting
and the firmware is checking if a PC card is
installed.
On steadily Indicates that the Routing Engine booted from
the PC Card.
