Using The Telnet Interface For Telnet Command Line Interface (Cli) Operation - Comtech EF Data CDM-625A Installation And Operation Manual

CDM-625A Advanced Satellite Modem
Ethernet-based Remote Product Management
7.4.2 Using the Telnet Interface for Telnet Command Line Interface (CLI)
Operation
Figure 7-1. CDM-625A Telnet Command Line Interface (CLI)
1) The CDM-625A Telnet Command Line Interface (CLI) is accessible only when you
install and enable the optional IP Packet Processor.
2) The CDM-625A Telnet CLI uses Telnet TCP Port 107. Be sure to specify this port
when configuring your terminal emulator for CLI operation.
3) The HyperTerminal terminal emulator, while compatible for use with remote
control operations, is not supported or recommended for CDM-625A Telnet CLI
operation. Instead, for best results Comtech EF Data recommends PuTTY or
Tera Term or as the preferred terminal emulators (Figure 7-1).
(LEFT) TeraTerm CLI Example
(RIGHT) PuTTY CLI Example
7–7
MN-CDM625A
Revision 4
