Unit Parameters - Comtech EF Data CDM-750 Installation And Operation Manual

CDM-750 Advanced High-Speed Trunking Modem
Serial-based Remote Product Management
7.5.5

Unit Parameters

Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
Local/Remote LRS= 1 byte, value
Status of 0 thru 4
Software Boot SBS= 1 byte, value
From Image of 1 or 2
Current N/A 1 byte, value
Software of 0 or 1
Circuit ID CID= 4 to 24 bytes
String
Date DAY= 6 bytes
Time TIM= 6 bytes
Description of Arguments
Command or Query.
Set or return the user's Local/Remote status in the form x, where:
0 = Local
1 = Serial Remote (RS-232/RS-485)
2 = reserved
3 = Ethernet Remote
4 = Ethernet plus Serial
LRS defaults to Ethernet plus Serial (LRS=4)
Example: LRS=0 (selects Local)
Command or Query.
Select or return which bulk firmware image to boot from, in the form x, where:
1 = Firmware is Image #1
2 = Firmware is Image #2
Example: SBS=1 (selects Image 1 Firmware)
Query only.
Return the active software image in the form x, where:
0 = Bulk Image #1 currently active
1 = Bulk Image #2 currently active
Command or Query.
Set or return the user-defined Circuit ID string, selects 4 to 24 characters in length.
Valid characters include: [Space] ( ) * + – . / 0 thru 9 and A thru Z
Command or Query.
Set or return a date in the form ddmmyy (European format), where
dd = day of the month (01 to 31)
mm = month (01 to 12)
yy = year (00 to38)
Example: DAY=240457 (April 24, 2057)
Command or Query.
Set or return the time in the form hhmmss, indicating the time from midnight, where:
hh = hours (00 to 23)
mm = minutes (00 to 59)
ss = seconds (00 to 59)
Example: TIM=231259 (23 hours:12 minutes:59 seconds)
7–18
Revision 2
MN-CDM750
Query
Response to
(Instruction & Response to Query
Command
Qualifier)
LRS= LRS? LRS=x
LRS? (see Description of
LRS* Arguments)
LRS#
SBS= SBS? SBS=x
SBS? (see Description of
SBS* Arguments)
SBS#
N/A IMG? IMG=x
(see Description of
Arguments)
CID= CID? CID=x
CID? (see Description of
CID* Arguments)
CID#
DAY= DAY? DAY=ddmmyy
DAY? (see Description of
DAY* Arguments)
DAY#
TIM= TIM? TIM=hhmmss
TIM? (see Description of
TIM* Arguments)
TIM#
