20.9.2 USB0 and USB1 Controller Registers
The USB0 and USB1 register descriptions are included in this section.
20.9.2.1

USB0 Controller Registers

Table 20-75 lists the registers for the USB0 Controller submodule.
Address Offset
1000h
1014h
1018h
1020h
1024h
1028h
102Ch
1030h
1034h
1038h
103Ch
1040h
1044h
1070h
1074h
1080h
1084h
1088h
108Ch
1090h
1094h
1098h
109Ch
10A0h
10A4h
10A8h
10ACh
10B0h
10B4h
10B8h
10D0h
10D4h
10D8h
10E0h
10E4h
10E8h
1400h–1468Ch
SPRUGX9 – 15 April 2011
Submit Documentation Feedback
Preliminary
Table 20-75. USB0 Controller Registers
Acronym USB0 Controller Register
USB0REV USB0 REVISION
USB0CTRL USB0 Control Register
USB0STAT USB0 Status Register
USB0IRQMSTAT USB0 IRQ_MERGED_STATUS
USB0IRQEOI USB0 IRQ_EOI
USB0IRQSTATRAW0 USB0 IRQ_STATUS_RAW_0
USB0IRQSTATRAW1 USB0 IRQ_STATUS_RAW_1
USB0IRQSTAT0 USB0 IRQ_STATUS_0
USB0IRQSTAT1 USB0 IRQ_STATUS_1
USB0IRQENABLESET0 USB0 IRQ_ENABLE_SET_0
USB0IRQENABLESET1 USB0 IRQ_ENABLE_SET_1
USB0IRQENABLECLR0 USB0 IRQ_ENABLE_CLR_0
USB0IRQENABLECLR1 USB0 IRQ_ENABLE_CLR_1
USB0TXMODE USB0 Tx Mode Register
USB0RXMODE USB0 Rx Mode Register
USB0GENRNDISEP1 USB0 Generic RNDIS Size EP1
USB0GENRNDISEP2 USB0 Generic RNDIS Size EP2
USB0GENRNDISEP3 USB0 Generic RNDIS Size EP3
USB0GENRNDISEP4 USB0 Generic RNDIS Size EP4
USB0GENRNDISEP5 USB0 Generic RNDIS Size EP5
USB0GENRNDISEP6 USB0 Generic RNDIS Size EP6
USB0GENRNDISEP7 USB0 Generic RNDIS Size EP7
USB0GENRNDISEP8 USB0 Generic RNDIS Size EP8
USB0GENRNDISEP9 USB0 Generic RNDIS Size EP9
USB0GENRNDISEP10 USB0 Generic RNDIS Size EP10
USB0GENRNDISEP11 USB0 Generic RNDIS Size EP11
USB0GENRNDISEP12 USB0 Generic RNDIS Size EP12
USB0GENRNDISEP13 USB0 Generic RNDIS Size EP13
USB0GENRNDISEP14 USB0 Generic RNDIS Size EP14
USB0GENRNDISEP15 USB0 Generic RNDIS Size EP15
USB0AUTOREQ USB0 Auto Req Register
USB0SRPFIXTIME USB0 SRP Fix Time
USB0TDOWN USB0 Teardown Register
USB0UTMI USB0 PHY UTMI Register
USB0UTMILB USB0 MGC UTMI Loopback Register
USB0MODE USB0 Mode Register
... USB0 Mentor Core Registers
