Goodrive3000 series medium voltage VFD
The function codes are used to set the reactive current closed-loop function when the synchronous motor is at VF mode.
Function
code
closed-loop integral
P04.36
P04.37
closed-loop voltage
P04.38
P04.39
P04.40
P04.41
P04.42
P04.43
P05 group––Input terminals
Function
code
P05.00
The function code is used to set the S8 input type.
Function
code
P05.01
P05.02
P05.03
P05.04
P05.05
P05.06
P05.07
P05.08
Name
Reactive current
0–400.00Hz
switch-over
frequency
Reactive current
closed-loop
0–5000
high-frequency
integral
Reactive
0–16000V
limit in PM-VF
control
IF enabling 0: Invalid
selection 1: Valid
IF control current 0.0–200.0%
IF control
0–5000
proportional gain
IF control integral
0–5000
gain
IF switching off
0.00–20.00Hz
frequency
Name
0: HDI is high-speed pulse input
HDI input type
1: HDI is digital input
Name
Function of S1
0: No function
terminal
1: Run forward
Function of S2
2: Run reversely
terminal
3: Three-wire running control
Function of S3
4: Jog forward
terminal
5: Jog reversely
Function of S4
6: Coast to stop
terminal
7: Reset faults
Function of S5 8: Pause running
terminal 9: External fault input
10: Increase frequency setting (UP)
Function of S6
11: Decrease frequency setting
terminal
(DOWN)
Function of S7
12: Clear the frequency
terminal
increase/decrease setting
Function of S8
13: Switch between A setting and B
terminal
Description
Description
Description
-81-
Goodrive3000 inverter
Setting range Default
0–400.00 50.00Hz
0–5000 30
0–16000 8000
0–1 0
0.0–200.0 50.0%
0–5000 350
0–5000 10
0.00–20.00 10.00Hz
Setting range Default
0–1 0
Setting range Default
0–63 1
0–63 4
0–63 7
0–63 0
0–63 0
0–63 0
0–63 0
0–63 0
