Goodrive3000 series medium voltage VFD
P02 group––Reserved parameters
Function code
P02.00–P02.07
P03 group––Control parameters
Function
code
Positive limit on active current
P03.06
Negative limit on active current
P03.07
Positive limit on reactive current
P03.08
Negative limit on reactive current
P03.09
P03.10
P03.06 indicates the maximum active current at rectifier output.
P03.07 indicates the maximum active current at energy feedback.
P03.08 indicates the maximum reactive current at rectifier output.
P03.09 indicates the maximum reactive current at energy feedback.
P03.10 indicates the max. current output limited by the rectifier automatic current limit function.
Function
code
P03.11
Voltage-loop integral
P03.12
P03.13
Voltage-loop integral
P03.14
P03.15
The absolute value of the difference between the DC voltage setting for the PI regulation in the voltage loop and the DC
voltage feedback is ∆.
When ∆ is less than the PI parameter switching voltage, PI parameter 1 is used. When ∆ is equal to or greater than the PI
parameter switching voltage, PI parameter 2 is used.
Function
code
P03.16
The function code indicates the bus voltage displayed on the keypad.
Name
Reserved
Name
(rectification)
(feedback)
(rectification)
(feedback)
Max. current setting
Name
Voltage-loop
proportional
coefficient 1
coefficient 1
Voltage-loop
proportional
coefficient 2
coefficient 2
PI parameter
switching voltage
Name
Bus voltage filter
coefficient
Description
Description
0.0–200.0% (of the rectifier rated
current)
0.0–200.0% (of the rectifier rated
current)
0.0–200.0% (of the rectifier rated
current)
0.0–200.0% (of the rectifier rated
current)
0–250.0% (of the rectifier rated
current)
Description
0.001–30.000
0.01–300.00
0.001–30.000
0.01–300.00
0.01–30.00V
Description
0–1.000s
-25-
Goodrive3000 rectifier
Setting range Default
Setting
Default
range
0.0–200.0% 150.0%
0.0–200.0% 150.0%
0.0–200.0% 150.0%
0.0–200.0% 150.0%
0.0–250.0% 200.0%
Setting range Default
0.001–30.000 2.000
0.01–300.00 20.00
0.001–30.000 5.500
0.01–300.00 10.00
0.01–30.000 10.00V
Setting range Default
0–1.000s 0.000s
