The curvature of S curve is determined by the ACC range, ACC/DEC time, starting time, and ending time.
Function
code
P01.08
0: Decelerate to stop. When a stop command takes effect, the VFD lowers output frequency based on the DEC mode and
the defined DEC time; when the frequency drops to 0Hz, the VFD stops.
1: Coast to stop. After a stop command takes effect, the VFD stops output immediately; and the load coasts to stop
according to mechanical inertia.
Function
code
Starting frequency of
P01.09
DC braking for stop
Wait time before DC
P01.10
DC braking current
P01.11
DC braking time for
P01.12
Starting frequency of braking for stop: During the deceleration to stop, the VFD starts DC braking for stop when running
frequency reaches the starting frequency determined by P01.09.
Wait time before braking: The VFD blocks the output before starting DC braking. After this wait time, DC braking is started
so as to prevent overcurrent caused by DC braking at high speed.
DC braking current for stop: It indicates the applied DC braking energy. Stronger current indicates greater DC braking
effect.
DC braking time for stop: It indicates the hold time of DC braking. If the time is 0, DC braking is invalid, and the VFD
decelerates to stop within the specified time.
Output frequency f
t1
Name
0: Decelerate to stop
Stop mode
1: Coast to stop
Name
0.00–P00.03 (Max. output frequency)
0.00–50.00s
braking for stop
0.0–100.0%
for stop current)
0.00–50.00s
stop
Acceleration
Braking time
before start
Run
command
t1=P01.06
t2=P01.07
t3=P01.06
t4=P01.07
Time t
t2 t3 t4
Description
Description
(of the VFD
Constant Decele-
speed ration
Wait time before DC
ON
OFF
-66-
Goodrive3000 inverter
Setting range
0–1
Setting range
0.00–P00.03
0.00–50.00
rated
0.0–100.0
0.00–50.00
Time t
DC braking
time for stop
braking for stop
Default
0
Default
0.00Hz
0.00s
0.0%
0.00s
