INVT Goodrive3000 Series Operation Manual page 183

Goodrive3000 series medium voltage VFD
Function
code
P12.04 Rated voltage of AM 2
P12.05 Rated current of AM 2
P12.06 Stator resistance of AM 2
P12.07 Rotor resistance of AM 2
P12.08 Leakage inductance of AM 2 0.1–6553.5mH
P12.09 Mutual inductance of AM 2 0.1–6553.5mH
P12.10 No-load current of AM 2
Magnetic saturation
P12.11 coefficient 1 of iron core of
Magnetic saturation
P12.12 coefficient 2 of iron core of
Magnetic saturation
P12.13 coefficient 3 of iron core of
Magnetic saturation
P12.14 coefficient 4 of iron core of
P12.15 Rated power of SM 2
P12.16 Rated frequency of SM 2
Number of pole pairs of SM
P12.17
P12.18 Rated voltage of SM 2
P12.19 Rated current of SM 2
P12.20 Stator resistance of SM 2
Direct-axis inductance of SM
P12.21
Quadrature-axis inductance
P12.22
Counter-emf constant of SM
P12.23
Initial pole position of SM 2
P12.24
Identification current of SM 2
P12.25
Name
0–4000V
0.8–6000.0A
0.001–65.535Ω
0.001–65.535Ω
0.1–6553.5A
0.0–100.0%
AM 2
0.0–100.0%
AM 2
0.0–100.0%
AM 2
0.0–100.0%
AM 2
0.1–3000.0kW
0.01Hz–P00.03
frequency)
1–50
2
0–4000V
0.8–6000.0A
0.001–65.535Ω
0.01–655.35mH
2
0.01–655.35mH
of SM 2
0–10000V
2
0x0000–0xFFFFH
(reserved)
0%–50% (of the motor rated
(reserved) current)
Description
(Max. output
-177-
Goodrive3000 inverter
Setting
Default Modify
range
Model
0–4000
depended
Model
0.8–6000.0
depended
0.001– Model
65.535 depended
0.001– Model
65.535 depended
Model
0.1–6553.5
depended
Model
0.1–6553.5
depended
Model
0.1–6553.5
depended
0.0–100.0 80.0%
0.0–100.0 68.0%
0.0–100.0 57.0%
0.0–100.0 40.0%
Model
0.1–3000.0
depended
0.01–P00.03 50.00Hz
1–50 2
Model
0–4000
depended
Model
0.8–6000.0
depended
0.001– Model
65.535 depended
Model
0.01–655.35
depended
Model
0.01–655.35
depended
0–10000 300V
0x0000–
0x0000
0xFFFFH
0–50
10%
◎
◎
○
○
○
○
○
◎
◎
◎
◎
◎
◎
◎
◎
◎
○
○
○
○
●
●
