INVT Goodrive3000 Series Operation Manual page 159

Goodrive3000 series medium voltage VFD
Function
code
Electromotive torque upper
P03.20
limit set through keypad
Braking torque upper limit
P03.21
set through keypad
Weakening coefficient in
P03.22
constant power zone
Lowest weakening point in
P03.23
constant power zone
P03.24 Max. voltage limit
P03.25 Pre-exciting time
Flux-weakening proportional
P03.26
P03.27 Flux-weakening integral gain 0–4000
Enabling SM integral
P03.28
Exciting current expansion
P03.29
coefficient in SVC 1 for AM
Speed feedforward
P03.30
coefficient in SVC 1 for AM
Speed feedforward limit in
P03.31
P04 group––V/F control
P04.00 V/F curve setting of motor 1
P04.01 Torque boost of motor 1
Name
2: AI2 (same as the above)
3: AI3 (same as the above)
4: Pulse frequency HDI (same as
the above)
5: MODBUS communication
(same as the above)
6: PROFIBUS/CANopen
communication (same as the
above)
7: Ethernet communication
(same as the above)
8: Reserved
0.0–300.0% (of the motor rated
current)
0.0–300.0% (of the motor rated
current)
0.1–2.0
10%–100%
0.0–120.0%
0.000–10.000s
0–4000
gain
0: Disable
separation 1: Enable
100–200
0.000–30.000
0.0–150.0%
SVC 1 for AM
0: Straight-line V/F curve
1: Multi-point V/F curve
2: Torque-down V/F curve
(power of 1.3)
3: Torque-down V/F curve
(power of 1.7)
4: Torque-down V/F curve
(power of 2.0)
5: Customized V/F curve (V/F
separation)
0.0%: (automatic)
0.1%–10.0%
Description
-153-
Goodrive3000 inverter
Setting
Default Modify
range
0.0–300.0 180.0%
0.0–300.0 180.0%
0.1–2.0 0.3
10–100 20%
0.0–120.0 100.0%
0.000–
0.300s
10.000
0–4000 300
0–4000 300
0–1 0
100–200 100
0.000–
0
30.000
0.0–150.0 30.0%
0–5 0
0.0–10.0 0.0%
○
○
○
○
◎
○
○
○
○
○
○
○
◎
○
